UHTD synthetic graphite sheet

Graphite sheet is a new type of thin film material made of polyimide by sintering and calendering.

It has high thermal conductivity, high electrical conductivity and excellent flexibility in product design.

According to different application, DASEN can provide graphite products with ordinary performance,

high performance and ultra-high performance.

Graphite sheets have excellent thermal conductivity, up to 2200W/mk. In fields such as electronic devices, power electronics, and LED lighting, graphite sheets can improve the heat dissipation effect of equipment and protect devices from damage caused by overheating.

Graphite sheets have excellent conductivity and can be used as conductive materials in electronic devices, batteries, electrodes, electromagnetic shielding, and other fields.


Features of graphite sheet:

  • Excellent thermal conductivity and electrical conductivity

  • Light specific gravity: 1.0~2.2g/cm3

  • Low thermal resistance, soft and easy to cut

  • Ultra thin, thickness: 0.017~0.15mm

  • It can be processed in combination with other materials such as metal, plastic, adhesive, etc


    Item No.

    DSN5065 UHTD

    DSN5070 UHTD

    DSN5085 UHTD

    DSN5100 UHTD

    Thickness (um)

    65 ± 6

    70 ± 7

    85 ± 9

    100 ± 10

    Thermal conductivity

            X-Y axis (w/m.k)

    ≥1800

    ≥1700

    ≥1700

    ≥1500

    Density (g/cm³)

    ≥2.1

    ≥2.1

    ≥2.10

    ≥1.90

    Heat capacity (J/g/K)

    0.85

    0.85

    0.85

    0.85

    Working temperature ()

    -40~400

    -40~400

    -40~400

    -40~400

    Bending times

           (angle 180, R5)

    20000

    20000

    20000

    20000

    Thermal capability

    ≥117,000

    ≥119,000

    ≥144,500

    ≥150,000
